Standing Seam Roof Panel Machine - Snap Lock | ZHONGYUAN
Standing Seam Roof Panel Machine - Snap Lock | ZHONGYUAN

Review

Description

Product Overview

ZHONGYUAN snap lock standing seam roof panel machine produces metal roofing panels with concealed fastener clip systems. The snap lock design allows for quick installation while providing superior weather sealing and thermal movement accommodation.

This machine is ideal for residential roofing, commercial buildings, and architectural metal roofing projects where clean lines and weathertight performance are essential. The panels feature a hidden clip system that eliminates exposed fasteners on the roof surface.

Technical Parameters

Material Thickness0.4-0.8mm
Seam TypeSnap Lock (Concealed Clip)
Forming Speed15-20m/min
Control SystemPLC + Touch Screen
Motor Power5.5-7.5kW
Voltage415V/50Hz/3Phase
